Model Name |
AMG-08OPHA02N1 |
|
Screen Size |
8.4" |
|
Active Display Area (mm) |
170.4(H) x127.8(V) |
|
Pixel Pitch (mm) |
0.213(H) x 0.213 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800x600 |
|
Contrast Ratio |
500:1 |
|
Display Color |
262K colors |
|
Brightness (CD/㎡) |
200 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
130(H); 110 (V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
210x149x25 |
|
Operating Temperature |
0～50℃ |
|
Storage Temperature |
-20～60℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
