Model Name |
AMG-18IPTL01T1 |
|
Screen Size |
18.5" |
|
Active Display Area (mm) |
409.8(H)x230.4(V) |
|
Pixel Pitch (mm) |
0.3(H)x0.3(V) |
|
Display Mode |
Normally White |
|
Display Resolution (pixel) |
1366x768 |
|
Contrast Ratio |
1000:1 |
|
Touch screen(optional) |
PCAP Touch(10 Points) |
|
Brightness (CD/m ) |
800 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
170Hx160V |
|
Response Time(Typ.Tr+Tf) |
5ms |
|
Signal Connector |
VGA/DVI/USB |
|
Power Consumption |
DC 24V |
|
Dimension(VxHxT) |
480x308x57.8 |
|
Operating Temperature |
0～50℃ |
|
Storage Temperature |
-20～60℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
