Model Name |
AMG-10IPHJ01T1 |
|
Screen Size |
10.4" |
|
Active Display Area(mm) |
211.2(H)x158.4(V) |
|
Pixel Pitch(mm) |
0.264(H)x0.264(V) |
|
Display Mode |
Normally white |
|
Display Color |
16.2M/262K |
|
Display Resolution(pixel) |
800x600 |
|
Contrast Ratio |
500:1 |
|
Brightness |
1000nits(Light Sensor) |
|
Backlight |
LED |
|
Viewing Angles(CR=10) |
160(H);130(V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Touch Screen |
PCAP Touch(10 points) |
|
Light Sensor |
Support |
|
Optical Bonding |
Support |
|
Signal Connector |
VGA/DVI-D |
|
Power Consumption |
DC 12V |
|
Touch Controller |
USB |
|
Dimension(VxHxT)mm |
295x205x40 |
|
Operating Temperature |
-20～70℃ |
|
Storage Temperature |
-20～70℃ |
|
Relative Humidity |
5[%RH]～90[%RH] |
