شاشات الكريستال السائل الجدار

Model Name

AMG-12IPTP01T1

Screen Size

12.1"

Active Display Area (mm)

245.76(H) x 184.32(V)

Pixel Pitch (mm)

0.24(H)x0.24(V)

Display Mode

Normally white

Display Resolution (pixel)

1024x768

Contrast Ratio

700:1

Display Color

16.2M/262K

Brightness (CD/㎡)

500

Backlight

LED

Viewing Angles (CR =10)

160(H)X160(V)

Response Time(Typ.Tr+Tf)

35ms

Signal Connector

VGA/DVI/DC2.0

Power Consumption

DC 12V

Dimension(VxHxT)

300X240X49

Operating Temperature

-30～80℃

Storage Temperature

-30～80℃

Relative Humidity

5(%RH)～90(%RH)
